Ship Hull Cleaning And Blasting System Water Jetting Equipment

loading

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
Availability:
Inquire Add to Basket

Product Description

Ship hull cleaning and blasting system

Ship hull cleaning and blasting system professional provider.

The hull of a ship is an important structural component of a vessel specifically engineered to support the contents of a ship and to be watertight. Hull (and propeller) maintenance is without a doubt important,we have complete solution to ensure such a importank task finished perfectly.


Our ship hull cleaning and blasting system designed for various vessel types, including bulk carriers, container ships, vehicle vessels, and oil tankers.

1742960740039
1742960728655
1742960722329

Technical Parameters

Working pressure range1500~3200bar
Flow rate30~57.5L/min
Max power250kw
Radio rate3.5 / 4.086 ;4.619 / 5.211
Pump speed450r/min
Cleaning efficiency30-90m2/h
Cleaning types3 kinds of tools available.
ControlRemote control and site conrol
Machine typePower supply and Diesel engine available



Solutions

removal-painting

First solution of ship hull cleaning and blasting system

High-pressure water jets are used to remove sediment from the ship during navigation, to remove growth, rust, paint and sea salt from the ship’s hull and hold, and to remove adhesions from the hold and bilge. Regular cleaning of the ship removes growth and algae from the hull surface and reduces the resistance to navigation. This reduces fuel consumption and ensures that the ship sails faster.

1743062421284


Second solution of ship hull cleaning and blasting system

The dock bottom trolley is suitable for cleaning flat counter-attack areas such as the flat bottom of a ship, as well as flat areas such as the deck; it can be used for manual breaking and other operations by replacing the rust removal head, Flexible and easy to use with recovery system.







1743062861266

Third solution of ship hull cleaning and blasting system

The rust remover is equipped with a vacuum rust remover to achieve ” instant dry” operation, and the rust slag and waste water generated during the rust removal process is recycled and discharged, thus reducing emissions and recycling the environment. It also eliminates the need for surface cleaning of steel plates, site cleaning and rework, providing a solution to the environmental problem of rust removal on ships









Previous:
Next:
Ship Hull Cleaning And Blasting System waterjetting water jetting equipment
As Head has a strong research and development, production sales and service team, Shenyang Head Science and Technology Co.,Ltd has become well-known enterprises in waterjet cutting machine manufacturer field.
