HEAD Water Cutting Cutting Plate And Pipeline Integrated Machine

5 0 Reviews
Cutting plate and pipeline integrated water cutting machine, one waterjet cutting machine, You can cut both pipe tube and plate material
Quantity:
  • HEAD
  • HEAD
  • HS code: 84565000

板管4


5-axis head took the tilting head a step beyond and cuts beveled and 3D parts with a 45 degree angle. 5-axis head gives you the ability to cut parts even faster with more accuracy than ever.


Water jet cutting head Technical Parameters

-Bevel axis (A): ±45°

-Rotary axis (C): ±540°

-Control accuracy: ±0.01mm

-Angle accuracy: 0.01°


Max 5 axis waterjet cutting head is based on the standard three-axis (x-axis Y-axis Z-axis) and adds the a-axis (rotation around x-axis) and the c-axis (rotation around z-axis), which can achieve large-angle deflection。By using state-of-the-art technology and Italian ECS control system, it can produce 0-±45° or more inclined cuts with a maximum rotation angle of up to ±540°.Therefore, it can achieve the effect of 3d waterjet cutting.

With Max 5 axis water jet cutting system HEAD WATER JET has been widely used in cutting industry with high-precision requirement, such as cutting cone, arc-shaped impeller, gear and other workpieces.

waterjet cutting machine



waterjet cutting machine



waterjet cutting machine
