Head special oil cooler for water cutting machine
The host adopts brand-new imported brand-name compressor, reliable operation, high efficiency, low noise, etc...
Imported brand special oil pump, high pressure, high stability, long-lasting durability...
Imported digital controller, high precision, wide range of use.
Can effectively control the oil temperature in any required range. Can work environment temperature at 45 degrees to maintain normal work.
  • HACW150PAT

Availability:

Product Description


recommended for high ambient temperature


Working principle: the working medium of the pressurized high-pressure pump is hydraulic oil, in the pressurization process, the hydraulic oil will gradually warm up, the temperature is too high will make the seals life greatly reduced. So in a certain cooling method to reduce the temperature of the hydraulic oil. High-pressure pumps are installed inside the plate heat exchanger. High-temperature hydraulic oil flows into the plate heat exchanger, the plate heat exchanger through the water circuit to cool down and then cool down the hydraulic oil, the water circuit within the plate heat exchanger through the external water cooler to provide water cooler will be low-temperature water pumped into the plate heat exchanger, plate heat exchanger cooling, and then heat exchange of high-temperature water pumped back to the water cooler, through the compressor within the water cooler and refrigerant cooling high-temperature return water, and so on!


Model

HACW150PAT

Mains power(V)

3PH/AC380±10%/50Hz

Using Conditions

Environmental requirements

5~55℃ below,Well-ventilated, no corrosive aerosols, no strong vibration sources

Water temperature(℃)

5~40

Solution type

pure water

Cooling Capacity

Kcal/h

15000

KW

17.5



Compactors

Version

Totally Hermetic Scroll Compressors

Configured power

6.5

No. of compressors

1


Cooling Fan

Version

Outer rotor axial fans

Fan power

0.85

Number (pcs)

1



Evaporator

Interface Size

DN25×2

Version

High-efficiency brazed stainless steel plate heat exchanger

Flux(L/Min)

100

pressure(kgf/cm²)

2~10

Temperature control range (℃)

5~25℃ Adjustable

Control precision

±1℃

Appearance dimensions


Width(mm)

800

Thichness (mm)

1000

High (mm)

1650

Water pump motor power(KW)

0.75

Water pump lift(m)

25

Flow (m³/h)

4

Water tank capacity (L)

140

Piping size (internal pipe thread interface)

G1″×G1″(diameter 25)

Refrigerant

R134a

Rated total power (KW)

7.8

Protective device

Refrigerant high and low voltage protection, overload/short circuit/delay protection, power supply phase loss/overvoltage/undervoltage protection
